XD-B54 Horizontal Combustibility Tester
The horizontal flammability tester can detect the relative burning rate and flame retardancy of textiles, especially automotive upholstery fabrics. Flame retardant properties of automotive interior materials under fault and abnormal conditions.
Use:
The horizontal flammability tester can detect the relative burning rate and flame retardancy of textiles, especially automotive upholstery fabrics. Flame retardant properties of automotive interior materials under fault and abnormal conditions.
Accessories: a set of sample clips, a light gun, two tanks of butane gas, a temperature recorder
Compliant with standards:
ISO 3795, JIS D1201, FZ/T 01028, GB 8410, GB/T 20953, FMVSS 302, SAE J369, GMW3232
Compliant with the standard:
EN71-2 2003
Technical parameter:
| Flammability chamber inner size | 381x203x356mm, bottom exhaust hole diameter 19mm, 10 |
| Inner frame size | 330mmx50mm |
| Sample holder | 356x100mm, thickness not exceeding 13mm |
| Number of samples | at least 5 pieces |
| Nozzle top distance to the sample surface | 19mm |
| Nozzle diameter | inner diameter 9.5mm |
| Nozzle angle | vertical |
| Flame height | 38mm |
| Flame burning time | 15s |
| Marking line distance | 254mm |
| Combustion gas | natural gas, coal gas or butane |
| Volume (WxDxH) | 57x26x37cm |
| Weight | ≈28Kg |
| Power supply | 1∮ AC 220V 50Hz 3A |
