XD-F221 Safety Shoes Impact Resistance Lab Testing Equipment
This machine lifts a certain weight of impact hammer to a specified height and then releases the impact hammer instantly to act on the steel head between the......
Product Description:
This machine lifts a certain weight of impact hammer to a specified height and then releases the impact hammer instantly to act on the steel head between the safety shoes to conduct an impact test, and then check the degree of subsidence of the steel head to understand the safety quality of the safety shoes. The anti-second impact function can safely eliminate the misjudgment caused by the second impact on the test. Safety Footware Impact Tester comply with EN, ANSI, BS, CSA regulations, The design is different among EN, ANSI, BS, CSA, so please prescribe the regulation when ordering.
Standards:
ANSI-Z41, BS EN-344, CSA-Z195, ISO-20344, LD-50, EN ISO 20344:2004, LD50-1994, ASTM F2412-11, EN12568-2010, CNS 6863-82, GB 4014 -1983, JIS-T8101:2000, AS/NZS 2210.2, GB/T 20991, GB 4014-1983, BS-953, ASTM F2413, LD50, CNS 6863-8, SANS 20345.
Specification:
Drop hammer weight | 20±0.2KG 22.7±0.2KG |
Impact edge | r3±0.1mm angle 90°±1° |
Falling altitude | 0～1300mm |
Release method | electromagnet release control |
Volume | 70×60×185cm |
Size (W*D*H) | about 300kg |
| Power supply | AC～220V 50HZ |
Previous : XD-F219 Fabric Taber Abrasion Tester Machine
Next : XD-F222 Footwear Compression and Puncture Resistance Tester
